Wacker Neuson PT3A Self Priming Trash Pump

Wacker Neuson PT3A Self Priming Trash Pump

Back to catalog
$2,327.40
In stock
Product Details
Brand: Wacker Neuson

Gasoline-powered, self-priming, 3-inch centrifugal pump with a Honda engine: ideally suited to dewatering tasks for solid materials with a diameter of up to 38 mm.


Highlights

  • Easy transport
  • Honda gasoline engine
  • Sturdy and durable


ENGINE Metric Imperial
Fuel management Carburettor Carburettor
Inclined position max. 20,0 ° 20,0 °
Engine operating mode four-stroke four-stroke
Engine speed 1 3.825 1/min 3.825 1/min
Consumption at Speed 1 3,0 L/Std 0,8 GPH US
Fuel consumption 2,20 L/Std 0,6 GPH US
Run Time at Speed 1 2,0 std 2,0 std
Standard (Power max.) SAE J1349 SAE J1349
Standard (Effective power) SAE J1349 SAE J1349
Tank capacity 5,30 l, 5,30 l 1,4 gal US, 1,4 gal US
Oil filling max. 1,10 l 0,3 gal US
Air cleaner Dry air filter Dry air filter
Power rating max. 5,9 kW 7,9 hp
Cooling air cooling air cooling
Exhaust-gas limit PDB_09_00034_01 PDB_09_00034_01
Oil specification SAE 10W-30 SAE 10W-30
Engine speed (Power max.) 3.600 1/min 3.600 1/min
Starter type Recoil starter Recoil starter
Oil filling min. 1,10 l 0,3 gal US
Engine type Gasoline engine Gasoline engine
Cylinder 1 1
Engine Manufacturer Honda Honda
Cylinder capacity 270 cm3 16,5 Inch3
Spark plug(s) Denso W20EPR-U, NGK BPR-6 ES Denso W20EPR-U, NGK BPR-6 ES
Kraftstofftyp Gasoline Gasoline
Oil volume incl. filter change 1,10 l 0,3 gal US
SHIPPING AND STORAGE Metric Imperial
Width for shipping 750 mm 29,5 "
Height for shipping 1.800 mm 70,9 "
Length for shipping 1.150 mm 45,3 "
MECHANICAL - OUTPUT DETAILS Metric Imperial
Flow rate max. 1.315 l/min 347,4 gal/mi
Suction head max. 7,5 m 24,6 Foot
Solid diameter max. 38,0 mm 1,5 "
Delivery height max. 29,5 m 96,8 Foot
Pump pressure max. 2,9 bar 42,1 psi
ELECTRICAL SYSTEM Metric Imperial
Electrode distance 0,70 - 0,80 mm 0,028 - 0,032 "
MECHANICAL DETAILS Metric Imperial
Operating weight 67,0 kg 147,7 lb
Length 673 mm 26,5 "
Intake-/Pressure socket-dia. 75 mm 3,0 "
Height 571 mm 22,5 "
Width 508 mm 20,0 "
