Wacker Neuson DPU130Le Reversible Vibratory Compactor
$49,390.90
In stock
Product Details
Brand:
Wacker Neuson
The most powerful vibratory plate in the world! Remote-control vibratory plate for soil compaction.
Highlights
- Extreme operating width
- Economical alternative to the roller
- Divided base plate
- Most powerful compaction performance on the market
- Variable, precise control
- Infra-red remote control with tried and tested safety features
Comes with
- Vibratory plate
- Remote control
- Operator's manual
- Machine configuration instructions
| OPERATING FLUIDS | Metric | Imperial |
| Cooling fluid type | Maintain Fricofin | Maintain Fricofin |
| Exciter oil volume | 1,20 l | 1,27 qt US |
| Hydraulic fluid type | MR 520 | MR 520 |
| Hydraulic fluid volume | 44,000 l | 46,5 qt US |
| Cooling fluid volume | 2,00 l | 2,1 qt US |
| Exciter oil type | 75W-90 API GL-4 | 75W-90 API GL-4 |
| ENGINE | Metric | Imperial |
| Inclined position max. | 25,0 ° | 25,0 ° |
| Engine operating mode | four-stroke | four-stroke |
| Operating Engine speed | 2.700 1/min | 2.700 1/min |
| Fuel consumption | 5,30 L/Std | 1,4 GPH US |
| Standard (Power max.) | ISO 3046 IFN | ISO 3046 IFN |
| Standard (Effective power) | ISO 3046 IFN | ISO 3046 IFN |
| Tank capacity | 18,00 l | 4,8 gal US |
| Nominal Engine speed | 2.700 1/min, 2.700 1/min | 2.700 1/min, 2.700 1/min |
| Oil filling max. | 3,00 l | 0,8 gal US |
| Effective power | 17,9 kW, 17,9 kW | 24,0 hp, 24,0 hp |
| Battery capacity (nom. value) | 50 Ah | 50 Ah |
| Air cleaner | Dry air filter | Dry air filter |
| Power rating max. | 24,5 kW | 32,9 hp |
| Cooling | Water-cooling | Water-cooling |
| Exhaust-gas limit | US: EPA TIER 4 - final + CARB, EU Stage V | US: EPA TIER 4 - final + CARB, EU Stage V |
| Oil specification | SAE 10W-40 | SAE 10W-40 |
| Starter battery Voltage | 12 V | 12 V |
| Engine speed (Power max.) | 3.600 1/min | 3.600 1/min |
| Starter type | E-starter | E-starter |
| Upper idling speed ex load | 2.800 1/min | 2.800 1/min |
| Operating power | 16,0 kW | 21,5 hp |
| Oil filling min. | 3,00 l | 0,8 gal US |
| Engine type | Diesel engine | Diesel engine |
| Cylinder | 4 | 4 |
| Engine Manufacturer | Kohler | Kohler |
| Standard (Operating power) | ISO 3046 IFN | ISO 3046 IFN |
| Cylinder capacity | 1.372 cm3 | 83,7 Inch3 |
| Kraftstofftyp | Diesel EN15940, Diesel EN 590 | Diesel EN15940, Diesel EN 590 |
| Oil volume incl. filter change | 3,20 l | 0,8 gal US |
| MECHANICAL - OUTPUT DETAILS | Metric | Imperial |
| Vibrations | 3.480 1/min | 3.480 1/min |
| Forward running | 31,00 m/min | 1,7 fps |
| Transmission | ELHY | ELHY |
| Gradeability | 46,0 % | 46,0 % |
| Centrifugal force | 130,000 kN | 29.225 lbf |
| Vibrations (Hz) | 58,0 Hz | 58,0 Hz |
| Area capacity | 2.232 m2/h | 24.025,2 ft2/h |
| HYDRAULIC | Metric | Imperial |
| Max. perm. hydraulic pressure | 175,0 bar | 2.537,5 psi |
| Operating pressure hydraulics | 140,0 bar | 2.030,0 psi |
| ELECTRICAL SYSTEM | Metric | Imperial |
| Remote Control Bat. Capacity | 12 h | 12 h |
| Coding options | 16 Kanäle | 16 Kanäle |
| Recommended Battery Typ | Ni-MH 7,2V/2000mAh | Ni-MH 7,2V/2000mAh |
| Charging Time | 1,90 h | 1,90 h |
| Remote Control Range | 23 m | 75,5 Foot |
| MECHANICAL DETAILS | Metric | Imperial |
| Lenght Drawbar in op. pos. | 1.270 mm | 50,0 " |
| Operating weight | 1.170,0 kg | 2.579,4 lb |
| Ground clearance | 996 mm | 39,2 " |
| Height | 996 mm | 39,2 " |
| Width | 1.202 mm | 47,3 " |
| ENVIRONMENT DATA | Metric | Imperial |
| Operating temperature range | -10 - 50 °C | 14 - 122 °F |
| Sound level LpA (Standard) | EN 500-4 | EN 500-4 |
| Sound power LWA, guaranteed | 109,0 dB(A) | 109,0 dB(A) |
| Storage temperature range | -20 - 50 °C | -4 - 122 °F |
| Sound level LpA | 87,0 dB(A) | 87,0 dB(A) |
| Sound power LWA (Standard) | EN 500-4 | EN 500-4 |
| Sound power LWA, measured | 108,0 dB(A) | 108,0 dB(A) |
| Custom Attributes | Metric | Imperial |
| Model serie | DPU |
